3) Carefully pull out the pressure piston using long nose pliers. Be careful
not to damage the grey sealing ring.
Figure 64: Removing the pressure piston
4) Using a syringe (e.g. from the chemist) or a pipette, fill in Magura brake
fluid (available form IFC / ISC), until the correct filling level is reached
(approx. 1.5 cm below the upper edge of the brake cylinder). Do not
use standard automobile brake fluid.
5) Reinstall the pressure piston and the aluminium cup
6) Screw out setting screw completely
7) Remount brake lever, cotter bolt and safety ring
8) Set the pressure point using the setting screw
9) Carry out a functional test of the brakes
