Ikco SAMAND - Changing Vehicle Lamps

144
5
Warning
The electrical system of your vehicle is designed standard or optional equipment.
Consult an authorized dealer before installing other electrical equipment. Some electrical
accessorier or the way in which they are tted can have damaging effects on the operation
of your vehicle; the electronic control circuit units, the audio system circuit or the battery
changing circuit. Installing electrical equipment should be carried out by an expert.
Fuse box of FN*
The fuse box locates in the right of the
engine compartment.
Detach clamps and remove the cover to
access the box. Make sure the cover is
correctly tted when replacing the cover.
Vehicle owner must not manipulate the
fuses .Any malfunctioning in this part must
be checked by authorized person.
Fuses function
Fuses
Ampere
FusesFuses function
Fuses
Ampere
Fuses
Horn30AF11Wiper motor30 AF1
Door feeding node
10AF12
AC compressor
15AF2
Alarm feedingWiper washer
ECU10AF14Double relay 230AF3
Right front fog lamp
15AF16
Double relay 130AF4
Left front fog lampABS brake 230AF6
Left front indicator
20AF17
ABS brake 130AF7
Left main beam lampsFan 130AF8
Left Night warning lampRight mirror heater
20AF9
Right dipped head lampsRight front mirror indicator
Right front indicator
20AF18
Right front window regulator
Right main beam lamps
Right front door functioning motor
Right Night warning lampRight mirror motor
Left dipped head lampsRight folding mirror
Central node feeding 240AF19Right front door light
Start feeding50AF20Map reading light key
Central node feeding 160AF21Door feeding node
Fan 240AF22 Left mirror heater
20AF10
Left front mirror indicator
Left front window regulator
Left front door functioning motor
Left mirror motor
Left folding mirror
Left front door light
Door feeding node
* If equipped
FUSES
