10
EN
INSTALLATION
Guidelines for nal positioning of refrigerator:
• All 4 corners of the cabinet must rest rmly on the oor.
• The front should be slightly elevated to ensure that doors close and seal properly.
• Doors should align with each other and be level.
Most of these conditions can be met by raising or lowering the adjustable anti-tip legs.
To level the cabinet using the anti-tip legs:
1. Slightly open freezer drawer to reveal anti-tip legs at bottom of cabinet.
2. Lower anti-tip legs until they are both touching the oor. Use a pair of pliers to adjust.
: turn leg clockwise if looking
from the top.
: turn leg counterclockwise if
looking from the top.
3. Ensure both doors are bind-free with their seals
touching the cabinet on all 4 sides and that
cabinet is stable.
NOTE
If your refrigerator is placed with the door hinge side against a wall, you may have to
allow additional space so the door can be opened wider.
1 in
56.75 in
25.4 mm
.37 in
9.5 mm
.37 in
9.5 mm
