INSTALLATION

NOTE
Product is shipped with doors adjusted to
the lowest position on the hinges.
Door
Door
To make nal door height adjustments:
1. Open freezer drawer to access hinges
for fresh food doors.
2. Insert 6 mm Allen
TM
wrench into the shaft
of the lower hinge (included with unit).
: turn adjustment
screw counterclockwise if looking at
the door from below.
: turn adjustment
screw clockwise if looking at the
door from below.
2. Adjust ipper mullion height. For proper
connection with the ipper mullion
guide, there should be a separation
about the thickness of a coin (0.060
inches, or 1.5 mm) between the guide
and ipper mullion.
3. Retighten screws.

1. Loosen the 2 screws located on the
ipper mullion hinge.

Adjust Flipper Mullion for proper connection
with the mullion guide by ensuring the
ipper mullion is folded and perpendicular
to the fresh food door. If the mullion guide
is not in the correct position, it could prevent
the door from closing completely.
WRONG

Flipper
Mullion
Mullion
Guide
Thickness
of a Coin

Flipper
Mullion
Screws
