Ikelite 6146.02 User Manual

32 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

Digital Housing

Instruction Manual

6146.02 for Canon G1 X Mark II

Thank you for your purchase of Ikelite equipment. Please read this

instruction manual completely before attempting to operate or dive

with this product. Please refer to the back page of this manual to

register your Ikelite product.

Table of Contents

Questions and Answers:

J
Jeffrey MilesJul 27, 2025
What to do if my Ikelite Camera Accessories housing fogs up?
- J
  Julia ChapmanJul 27, 2025
  If fogging occurs on the lens port of your Ikelite camera housing, it's likely due to humid air trapped inside. The camera produces heat, which can condense any trapped moisture, forming fog on the lens port. To resolve this: * Close the housing in an air-conditioned environment. * Avoid direct sunlight exposure for extended periods. * Use desiccant packs (moisture munchers) inside the housing. * Clean the main housing o-ring and sealing surface of the housing.
A
Alex CooperAug 3, 2025
Why won't my Ikelite Camera Accessories take a picture?
- T
  Tara Richardson DDSAug 3, 2025
  If your camera isn't taking pictures inside the Ikelite housing, consider these possible causes and solutions: * Install a fully charged battery. * Ensure sufficient light for focusing; consider adding a focusing light or strobe. * Select a center focus point in your camera menu. * Return Zoom control to the “disengaged” position. * Make sure the camera is mounted properly in the housing and controls are out of the way. * Main housing o-ring is not seated properly. * Hotshoe cord is in the way. * Step Ring is not engaging housing gear properly.
T
tracystewartAug 11, 2025
What should I do if water enters my Ikelite Camera Accessories housing?
- M
  Matthew DyerAug 11, 2025
  If water enters your Ikelite housing, take these steps: * Remove, clean, and properly lubricate the main o-ring. * Inspect the o-ring seal for any hair, dirt, or foreign debris. * Reassemble the housing without the camera and immerse it in water to check for leaks.
D
Daniel LewisAug 18, 2025
How to fix blue or green pictures with Ikelite Camera Accessories?
- R
  Regina ParkerAug 18, 2025
  If your pictures are too blue or green when using Ikelite Camera Accessories, here's what you can do: * Use custom (manual) white balance, resetting it for each working depth or when attaching a color correcting filter. * Add an external strobe. * Move closer to your subject. * Add an optional color correcting filter to the Housing Port.
