Appendix A: Technical Specifications
The table below lists technical specifications of the Illustra Flex Outdoor Bullet cameras.
General Features
Model Type Illustra Flex Outdoor Bullet Camera
Model No.
IFS03B1BNWIT / IFS08B2ONWIT /
IFS03B1ONWIT / IFS08B2ONWITA
Camera Body Color White
Vandal Resistant Rating
3MP (IFS03B1BNWIT) = IK7
3MP (IFS03B1ONWIT) = IK10
8MP (IFS08B2ONWIT)= IK9
8MP (IFS08B2ONWITA)= IK10
Mechanical Features
Dimensions
3MP (IK7) = Ø70 x 223 mm
3MP (IK10) and 8MP (IK9 & IK10) = Ø77.5 x 235
mm
Weight approximately 1.1kg
Pan Rotation Angle 360°
Tilt Angle 90°
Z-axis Rotation 360°
Housing Material Aluminum Alloy
Other Housing Material PC
Video Processor
ROM/Flash Size 256 Mbytes
RAM Size 512 Mbytes
RTC Hold Up Time 24 hours
Image Sensor
Format
3MP (IK7 & IK10) = 1/2.8 CMOS
8MP (IK9 & IK10) = 1/2.5''
Capture Method Rolling
Scan Method Progressive
Lens
Design Type
3MP (IK7 & IK10) = Varifocal 6 groups 8
elements
8MP (IK9 & IK10) = 6 groups 10 elements
Mount Phi 14mm
Aperture Range
3MP (IK7 & IK10) = F/1.4(W) ~ F/2.7(T)
8MP (IK9 & IK10) = F/1.5(W) ~ F/2.91(T)
