Appendix B: Stream Resolutions
Flex Gen 2 3MP and Flex 8MP Streaming Combinations
Table 19 on page 20 and Table 20 on page 21 provide information for the stream resolutions and
supported FPS of the Flex Gen 2 3MP cameras herein. Table 21 on page 22 provides information for
the stream resolutions and supported FPS of the Flex 8MP cameras.
Table 19 Stream Set A (all resolution, codes and frame rate combinations of Stream 1, 2 and 3 are
valid)
Flex 3MP Bullet camera resolutions
Stream
Resolution
Codecs
Frame
Rates (fps)
Stream
Resolution
Codecs
Frame
Rates (fps)
Stream
Resolution
Codecs
Frame
Rates (fps)
TWDR
Support
Stream 1 Stream 2 Stream 3
2048x1536
H264/H264
IntelliZip
H265/H26
IntelliZip
1-30 1280x720
H264/H264
IntelliZip
H265/H26
IntelliZip
MJPEG
1-30 640x360 MJPEG 7-15
Yes
(2x)
1920x1080
H264/H264
IntelliZip
H265/H26
IntelliZip
MJPEG
1-30 1024x576
H264/H264
IntelliZip
H265/H26
IntelliZip
MJPEG
1-30 480x360 MJPEG 7-15
Yes
(2x)
1664x936
H264/H264
IntelliZip
H265/H26
IntelliZip
MJPEG
1-30 640x360
H264/H264
IntelliZip
H265/H26
IntelliZip
MJPEG
1-30 384x288 MJPEG 7-15
Yes
(2x)
1280x720
H264/H264
IntelliZip
H265/H26
IntelliZip
MJPEG
1-30 480x360
H264/H264
IntelliZip
H265/H26
IntelliZip
MJPEG
1-30
Yes
(2x)
384x288
H264/H264
IntelliZip
H265/H26
IntelliZip
MJPEG
1-30
Yes
(2x)
