Ilsintech SWIFT KF4 - PRODUCT SPECIFICATIONS AND COMPONENTS; PRODUCT SPECIFICATIONS; PRODUCT PACKAGE

PRODUCT SPECIFICATIONS AND COMPONENTS
2.1| PRODUCT SPECIFICATIONS
CATEGORY DESCRIPTION
2.1.2| PRODUCT PACKAGE
2.2.2| OPTIONAL ACCESSORIES
CATEGORY MODEL Q’TY
CATEGORY MODEL
CAUTIONS
Use the KF4 only on a stable surface to avoid falls that may cause damage or injury.
The KF4 should be accurately adjusted and treated in alignment. Do not give it a strong shock. Use the
carrying case provided for transporting and storing the KF4 to reduce humidity, vibration and shock.
When replacing the electrodes:
• Always use UCL SWIFT-approved replacements
• Ensure correct positioning
• Always replace in pairs
Failure to follow all warnings and cautions to ensure proper function of the KF4 may result in equipment
damage or a faulty splice.
Use only ethyl alcohol (96% or higher) or other approved cleaning solutions to clean the lens, V-groove, LCD
monitor and main body.
Use the splicer only within the stated operating environmental ranges. Store in a controlled environment to
avoid long-term exposure to damaging temperatures and humidity levels.
The KF4 should receive regular service by a UCL SWIFT-authorized service technician to ensure long-term
functionality and safety.
Cleaver blade
BI-07
Electrode
EI-24
Work belt
WB-01
Work table
WK-02
Sleeve
S09-C, S09, S30-C, S30
SOC connector
SC, LC, FC, ST
External power
DC 12V (available for car cigar jack)
Optical fiber holder
HS-2.5, HS-IN, KF4-ST-01
!
Fiber alignment
IPAAS, Active V-Groove Alignment
Applicable type of fibres
SM (G.652; MM (G.651); DS (G.653); NZDS (G.655); SM (G.657 A1, A2/B2, B3)
Fiber count
Single fiber
Applicable fiber dimensions
Cladding diameter: 125µm; Coating diameter: 150µm-3mm
Fiber setting and cleaved length
7mm to 16mm (0.28in to 0.63in)
Splicing modes
Splice mode: 300; Heat mode: 100
Typical splice loss
SM: 0.03dB; MM: 0.01dB; DS:0.05dB; NZDS:0.05dB
Return loss
>60dB
Splicing time
Typical 7 sec. with SM
Splice loss estimate
Available
Sleeve heating time
Typical 13 sec. with IS-60 mode, IS-60 sleeve
Applicable protection sleeve
40mm (2.4in); 60mm (1.5in) micro sleeve
Storage of splice result
Data: up to 5,000 ea; Image: up to 5,000 ea
Tension test
1.96N to 2.25N
Operating condition
Altitude: 0-5,000m above sea level; Temperature: -10ºC~50ºC (-14ºF~122ºF);
Humidity: 0-95%; Wind: 15m/s, non-condensing, dust proof, water proof, shock proof
Storage condition
Temperature: -40ºC~80ºC (40ºF~176ºF); Humidity: 0-95%
Dimension
124(W) x 189(L) x 75(H)mm (without rubber protector)
Weight
1.1kg (including battery)
Viewing method and display
2 AXIS Two CMOS cameras with 109mm (4.3in) color LCD monitor
Fiber view and magnification
X/Y: 130X; Max: 260X
Power supply
Li-ion battery (DC 14.8V, 3400mAh); 100~240V AC charger
No. of splice cycles with battery
Typical 200 cycles
Electrode life
Up to 38,000 splices
Blade life
Up to 77,000 cleaves
Terminals
USB
Arc fusion splicer
SWIFT KF4
1
Battery
KF-3400
1
Battery adapter
FY1701000
1
Instructions for use
—
1
Spare electrode
EI-24
1 pair
Transporting case
Hard case
1
Cooling tray
CT-01 (40mm(1.5in))
1
Screw driver
LD-3300
1
USB cable
—
1
Sleeve clamp
SC-01
1
Cleaver
CS-01BT
1
Manual stripper
CF-02
1
Alcohol dispenser
POM
1
Cleaning brush
Tweezer
Optical fiber holder
—
—
HS-250(Pair), HS-900(Pair),
LS-900L(Loose tube),
KF4-SC/FC, KF4-ILC
1
1
