Image 6.5 - Part List

Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice.
Part List—Model No. IMSY59400
R0401A
Key No. Qty. Description Key No. Qty. Description
1 1 Butterfly Upright
2 1 Press Upright
3 1 Butterfly Front Leg
4
1 Butterfly Base
5 1 Weight Base
6 1 Press Base
7 1 Press Seat Frame
8 1 Press Frame
9 1 Weight Upright
10 1 Right Butterfly Arm
11 1 Left Butterfly Arm
12 1 Butterfly Backrest
13 2 Seat
14 1 Butterfly Seat Frame
15 2 Weight Guide
16 1 Top Weight
17 1 Weight Tube
18 1 Weight Tube Bumper
19 1 Weight Pin
20 1 Press Front Leg
21 19 Weight
22 1 Pulley Frame
23 4 Adjustable Pulley Plate
24 22 3 1/2” Pulley
25 14 Cable Trap
26 1 Weight Support
27 3 “V”-Pulley
28 19 2” Square Inner Cap
29 2 Butterfly Foam Pad
30 4 Foam Roller
31 4 Retainer Ring
32 3 Large Cable Trap
33 1 Right Support Frame
34 1 Shroud
35 3 1 3/4” Square Inner Cap
36 16 5/16” Washer
37 2 Butterfly Arm Bushing
38 2 1” Round Outer Cap
39 4 Plastic Grip
40 1 Bumper
41 1 Leg Lever
42 2 Pad Tube
43 4 3/4” Round Inner Cap
44 1 Row Bar
45 1 1/4” x 2 1/2” Carriage Bolt
46 3 3/8” x 2 3/4” Bolt
47 2 Pulley Cover
48 17 3/8” Flat Washer
49 8 1/4” x 3/4” Bolt
50 24 3/8” Nylon Locknut
51 2 Weight Bumper
52 1 3/8” x 9” Bolt
53 2 3/8” x 2 1/2” Bolt
54 7 3/8” x 2” Bolt
55 2 3/8” x 6 1/2” Bolt
56 3 3/8” x 3 1/2” Bolt
57 5 3/8” x 1 3/4” Bolt
5
8 1 Nylon Strap
59 6 3/8” x 3 3/4” Bolt
60 1 3/8” x 4” Bolt
61 1 Lat Bar
62 1 3/8” x 3 1/4” Bolt
63 11 3/8” Nylon Jam Nut
64 32 5/16” Nylon Locknut
65 3 Seat Plate
66 4 5/16” x 3 3/4” Bolt
67 1 Chain
68 3 1/4” Nylon Locknut
69 4 Cable Clip
70 2 Backrest Adjustment Frame
71 8 1/4” Flat Washer
72 1 Weight Cable
73 1 Butterfly Cable
74 1 Ab Cable
75 1 Low Cable
76 2 1” Inner Cap
77 2 Press Arm
78 4 Nylon Jam Nut
79 1 1/4” x 2 1/2” Bolt
80 1 1” Tap Screw
81 1 Ab Strap
82 3 1 1/4” Square Inner Cap
83 6 1” x 2” Inner Cap
84 2 3/8” x 1” Bolt
85 3 Adjustment Handle
86 2 Small Grip
87 2 Butterfly Grip
88 2 Press Grip
89 18 5/16” x 2 3/4” Bolt
90 1 Seat Adjustment Frame
91 1 Curl Pad
92 10 5/16” x 2 1/2” Carriage Bolt
93 1 Workout Decal
94 38 Weight Insert
95 3 1/4” x 5/8” Screw
96 1 3/8” x 1 1/4” Button Head Bolt
97 1 Left Support Frame
98 1 1/2” Flat Washer
99 1 Press Backrest
100 1 1/2” Plain Nut
101 2 1/4” x 1 1/2” Carriage Bolt
102 2 5/8” x 1/2” Spacer
103 4 1/4” x 1 1/2” Bolt
104 1 Plastic Weight Cover
105 1 1/2” x 3/4” Spacer
106 4 1/4” x 1 1/2” Screw
# 1 Userʼs Manual
