Chapter 5
Specifications
142
Copyright © 2004-2007, 2008, 2010, Harris Corporation
600 Analog
Audio
(P-12×1A2L)
Table 5-7 600 Analog Audio Input Specifications
Item Specification
Number of inputs 12 stereo channels
Signal type Balanced analog audio
Connector DB-62 (terminal strip adapters
available)
Impedance 600
CMRR > 55 dB rejection @ 60 Hz
Maximum level +20 dBm
Table 5-8 600 Analog Audio Output Specifications
Item Specification
Number of outputs 2 stereo channels (identical signals)
Signal type Balanced analog audio
Connector DB-62 (terminal strip adapters
available)
Impedance 600
Maximum level +20 dBm
DC offset < ± 50 mV
Table 5-9 600 Analog Audio Performance Specifications
Item Specification
Gain Unity, ±0.1 dB
THD+N <0.01%, 20 Hz to 20 kHz, +18 dBm
IMD (SMPTE 4:1) <0.01%, +18 dBm
Crosstalk >90 dB isolation, 20 Hz to 20 kHz, all
hostile
Frequency response <±0.1 dB, 20 Hz to 20 kHz
–3 dB point: >200 kHz
Signal to noise ratio >110 dB ref. to +18 dBm, 20 Hz to 20
kHz
