IMC MISTRAL 13 Series User Manual

6 MISTRAL M60, M90, M135 AND TC60
REVERSING DIRECTION OF DOOR (TC60)
On delivery the door of the Mistral TC60 is hinged on the right hand side of the
cabinet. However, it is possible to move the hinge to the other side of the
cabinet by following the steps below.
To change the TC60 door:
· Remove the grille cover by moving the cover upwards and then unhooking
the lugs from the bottom of the cabinet.
· Hold the door in its closed position to prevent the door from dropping when
the hinge fixings are removed.
· Unscrew the hinge fixings.
· Remove the hinge and triangular spacer.
· Place the door on the ground.
HINGE
FASTENERS
SPACER
GRILLE COVER
· Remove the Nylon bush which is located on the underside of the worktop
and push it into the hole on the left hand side.
