14 MISTRAL M60, M90, M135 AND TC60

CHANGING A FLUORESCENT STRIP LIGHT FITTING M60, M90, M90SD &

M135

The M60, M90, M90SD & M135 cabinet interior is illuminated by a fluorescent

fitting located at the front of the top inner panel. The switch is located at the left-

hand end of the strip light fitting.

To change the fitting:

· Open the front cabinet door(s)

· Ensure the mains power to the unit has been turned off

· Slide the fitting to the left

· Pull the fitting out from the key-hole slots

· Remove power cable from the right-hand end of the fitting

· Connect the new fitting to the power cable and insert into the key-hole slots

· Slide the fitting to the right until it stops

· Re-connect the mains power and ensure the light illuminates by means of

the switch.
