MISTRAL M60, M90, M135 AND TC60 5
INSTALLATION
For the Installer:
These Instructions contain important information designed to help the user
obtain the maximum benefit from their investment in an IMC Mistral.
Please read them carefully before starting work, and consult with the supplier in
the event of any queries.
Be sure to leave this Instruction Manual with the user after installation of the
machine is complete.
Procedure
WARNING
The following table shows the weight and the minimum quantity of
people required to lift each unit:
Bottle Cooler Net Weight Quantity of
People
M60 52 kg 2
M90 82 kg 4
M135 125 kg 4
TC60 87 kg 4
Install the unit on a flat and level floor. The Mistral M60 and M90 require 20mm
clearance for air circulation at the back and sides. The units are fitted with glider
feet which allow them to slide forward for cleaning and maintenance purposes.
The Mistral TC60 requires a clearance of 40 mm at the back of the unit.
The Mistral M135 is on castors to aid installation and removal for cleaning. Do
not install the unit close to a heat source such as a radiator or the warm air
outlet of another piece of refrigeration equipment.
Ensure that the units are standing level by adjusting the feet on either end of the
front of the unit.
The units have an automatic defrost cycle and evaporate all the condensate
water without the need for a drainage system.
NOTE
The castors on the Mistral M135 are to aid installation only. The unit is
not designed as a mobile machine.
It is important to install the Bottle Cooler on a flat surface. This ensures
that the doors are level. Adjustment is provided via the feet, to enable the
installer to level the cabinet. Engineer Call-outs in order to level Bottle
Coolers, will not be covered under warranty.
