8 MISTRAL M60, M90, M135 AND TC60
HINGE PIN
HANDLE
FASTENERS
· Refit the door making sure the hinge pin is inserted into the nylon bush
which is in the worktop.
· Refit the hinge and screw in the fasteners making sure the triangular spacer
is clamped between the hinge and the cabinet.
· Refit the grille cover as described at the beginning of this section.
