Nemo 96HD+
07/17 10783482 WEB E cod.MF9602.A
11
Display
Display is divided into four menus, accessible with their relevant function keys. Acting on the function keys it is possible to scroll the different available measurements:
Display
Reset
Simultaneously acting on the function keys, it is possible to reset the display pages:
Phase voltage Phase current Active power Active energy
Interlinked voltage Neutral current Reactive power Reactive energy
Min. voltage value
Average current Apparent power Power factor
Max. voltage value Medium current peak Average power Frequency
Voltage harmonic distortion Average 3 currents Average power peak Run hour meter
Configuration data Current harmonic distortion Configuration data Page custom view
Configuration data Configuration data
+
Bargraph
Percentage value related to Full Scale
Measure
To Next Page
