BLOCK 3
Positive active energy (block 3.1)
This is, conventionally, the energy actually consumed by the user.
Format : DWORD
Measurement unit :
Transformer ratio Measurement unit
1 < KTA*KTV < 10
xxxxxx.yy kWh
10 < KTA*KTV < 100
xxxxxxx.y kWh
100 < KTA*KTV < 1000
xxxxxxxx kWh
1000 < KTA*KTV < 10000
xxxxxx.yy MWh
10000 < KTA*KTV < 100000
xxxxxxx.y MWh
Positive reactive energy (block 3.2)
Format : DWORD
Measurement unit :
Transformer ratio Measurement unit
1 < KTA*KTV < 10
xxxxxx.yy kvarh
10 < KTA*KTV < 100
xxxxxxx.y kvarh
100 < KTA*KTV < 1000
xxxxxxxx kvarh
1000 < KTA*KTV < 10000
xxxxxx.yy Mvarh
10000 < KTA*KTV < 100000
xxxxxxx.y Mvarh
Negative active energy (block 3.3)
Same as block 3.1
Negative reactive energy (block 3.4)
Same as block 3.2
