IME NEMO 96 HD+ - Assignment of Measurements

PROTOCOL COMMUNICATION
PT10789220
pag. 7/22
6. Assignment of measurements
Telegram Number 1 = Block Number 1
Input byte Value NEMO 96HD Byte Format Note
Base
address +
0 Header byte 0 (Returned Block Number) Decimal = 1
1 Header byte 1 (not used)
2 Header byte 2 (not used)
3 Header byte 3 (Status) 8 Bit binary
4 Phase 1 : phase voltage MSB DWORD
5 MB2
6 MB1
7 LSB
8 Phase 2 : phase voltage MSB DWORD
9 MB2
10 MB1
11 LSB
12 Phase 3 : phase voltage MSB DWORD
13 MB2
14 MB1
15 LSB
16 Phase 1 : phase current MSB DWORD
17 MB2
18 MB1
19 LSB
20 Phase 2 : phase current MSB DWORD
21 MB2
22 MB1
23 LSB
24 Phase 3 : phase current MSB DWORD
25 MB2
26 MB1
27 LSB
28 Neutral current MSB DWORD
29 MB2
30 MB1
31 LSB
