PROTOCOL COMMUNICATION
PT10789220
pag. 8/22
Telegram Number 2 = Block Number 2
Input byte Value NEMO 96HD Byte Format Note
Base
address +
0 Header byte 0 (Returned Block Number) Decimal = 2
1 Header byte 1 (not used)
2 Header byte 2 (not used)
3 Header byte 3 (Status) 8 Bit binary
4 Chained voltage 1-2 MSB DWORD
5 MB2
6 MB1
7 LSB
8 Chained voltage 2-3 MSB DWORD
9 MB2
10 MB1
11 LSB
12 Chained voltage 3-1 MSB DWORD
13 MB2
14 MB1
15 LSB
16 3-Phase: active Power MSB DWORD
17 MB2
18 MB1
19 LSB
20 3-Phase: reactive Power MSB DWORD
21 MB2
22 MB1
23 LSB
24 3-Phase: apparent Power MSB DWORD
25 MB2
26 MB1
27 LSB
28 Active Power sign HB WORD
29 LB
30 Reactive Power sign HB WORD
31 LB
