IME NEMO 96 HD+ - Page 9

PROTOCOL COMMUNICATION
PT10789220
pag. 9/22
Telegram Number 3 = Block Number 3
Input byte Value NEMO 96HD Byte Format Note
Base
address +
0 Header byte 0 (Returned Block Number) Decimal = 3
1 Header byte 1 (not used)
2 Header byte 2 (not used)
3 Header byte 3 (Status) 8 Bit binary
4 3 phase : positive active energy MSB DWORD
5 MB2
6 MB1
7 LSB
8 3 phase : positive reactive energy MSB DWORD
9 MB2
10 MB1
11 LSB
12 3 phase : negative active energy MSB DWORD
13 MB2
14 MB1
15 LSB
16 3 phase : negative reactive energy MSB DWORD
17 MB2
18 MB1
19 LSB
20 Power Factor 3-phase HB WORD
21 LB
22 Power Factor Sector HB WORD
23 LB
24 Frequency HB WORD
25 LB
26 3-Phase : average power MSB DWORD
27 MB2
28 MB1
29 LSB
30 3 phase : peak maximum demand MSB DWORD
31 MB2
