IME NEMO 96 HD+ - Page 10

PROTOCOL COMMUNICATION
PT10789220
pag. 10/22
Telegram Number 4 = Block Number 4
Input byte Value NEMO 96HD Byte Format Solution
Base
address +
0 Header byte 0 (Returned Block Number) Decimal = 4
1 Header byte 1 (not used)
2 Header byte 2 (not used)
3 Header byte 3 (Status) 8 Bit binary
4 3 phase : peak maximum demand MB1
5 LSB
6 Average power pointer HB WORD
7 LB
8 Phase 1 : phase active power MSB DWORD
9 MB2
10 MB1
11 LSB
12 Phase 2 : phase active power MSB DWORD
13 MB2
14 MB1
15 LSB
16 Phase 3 : phase active power MSB DWORD
17 MB2
18 MB1
19 LSB
20 Phase 1 : active power sign HB WORD
21 LB
22 Phase 2 : active power sign HB WORD
23 LB
24 Phase 3 : active power sign HB WORD
25 LB
26 Phase 1 : phase reactive power MSB DWORD
27 MB2
28 MB1
29 LSB
30 Phase 2 : phase reactive power MSB DWORD
31 MB2
