IME NEMO 96 HD+ - Page 11

PROTOCOL COMMUNICATION
PT10789220
pag. 11/22
Telegram Number 5 = Block Number 5
Input byte Value NEMO 96HD Byte Format Note
Base
address +
0 Header byte 0 (Returned Block Number) Decimal = 5
1 Header byte 1 (not used)
2 Header byte 2 (not used)
3 Header byte 3 (Status) 8 Bit binary
4 Phase 2 : phase reactive power MB1
5 LSB
6 Phase 3 : phase reactive power MSB DWORD
7 MB2
8 MB1
9 LSB
10 Phase 1 : reactive power sign HB WORD
11 LB
12 Phase 2 : reactive power sign HB WORD
13 LB
14 Phase 3 : reactive power sign HB WORD
15 LB
16 Phase 1 : phase apparent power MSB DWORD
17 MB2
18 MB1
19 LSB
20 Phase 2 : phase apparent power MSB DWORD
21 MB2
22 MB1
23 LSB
24 Phase 3 : phase apparent power MSB DWORD
25 MB2
26 MB1
27 LSB
28 Phase 1 : Power Factor HB WORD
29 LB
30 Phase 2 : Power Factor HB WORD
31 LB
