PROTOCOL COMMUNICATION
PT10789220
pag. 12/22
Telegram Number 6 = Block Number 6
Input byte Value NEMO 96HD Byte Format Note
Base
address +
0 Header byte 0 (Returned Block Number) Decimal = 6
1 Header byte 1 (not used)
2 Header byte 2 (not used)
3 Header byte 3 (Status) 8 Bit binary
4 Phase 2 : Power Factor HB WORD
5 LB
6 Phase 1 : power factor sector HB WORD
7 LB
8 Phase 2 : power factor sector HB WORD
9 LB
10 Phase 3 : power factor sector HB WORD
11 LB
12 Phase 1 : THD phase V1 or V1-2 HB WORD
13 LB
14 Phase 2 : THD phase V2 or V2-3 HB WORD
15 LB
16 Phase 3 : THD phase V3 or V3-1 HB WORD
17 LB
18 Phase 1 : THD phase current HB WORD
19 LB
20 Phase 2 : THD phase current HB WORD
21 LB
22 Phase 3 : THD phase current HB WORD
23 LB
24 Phase 1 : thermal current MSB DWORD
25 MB2
26 MB1
27 LSB
28 Phase 2 : thermal current MSB DWORD
29 MB2
30 MB1
31 LSB
