IME NEMO 96 HD+ - Page 13

PROTOCOL COMMUNICATION
PT10789220
pag. 13/22
Telegram Number 7 = Block Number 7
Input byte Value NEMO 96HD Byte Format Note
Base
address +
0 Header byte 0 (Returned Block Number) Decimal = 7
1 Header byte 1 (not used)
2 Header byte 2 (not used)
3 Header byte 3 (Status) 8 Bit binary
4 Phase 3 : thermal current MSB DWORD
5 MB2
6 MB1
7 LSB
8 Phase 1 : peak of thermal current MSB DWORD
9 MB2
10 MB1
11 LSB
12 Phase 2 : peak of thermal current MSB DWORD
13 MB2
14 MB1
15 LSB
16 Phase 3 : peak of thermal current MSB DWORD
17 MB2
18 MB1
19 LSB
20 3 phase : partial positive active energy MSB DWORD
21 MB2
22 MB1
23 LSB
24 Current ratio KTI HB WORD
25 LB
26 Voltage ratio KTV HB WORD
27 LB
28 Ratio KTI*KTV*10 HB WORD
29 LB
30
31
