Nemo D4-e
07/17 10783591 WEB E cod.MFD4E06
10
Confirm programmed data
OK to confirm
OK to confirm
2.0 Password 2001
Press the key several times until the page is displayed:
Type of communication
Connection
Keep the key pressed until the page is displayed:
Set password 2001 and confirm
move the cursor
increase/decrease the set value
OK to confirm
2.1 External CT ratio
Ct = External CT primary/secondary ratio (e.g. CT 800/5A Ct = 160)
External CT ratio (Ct): 1...9999 (maximum primary current 50000/5A)
move the cursor
increase/decrease the set value
OK to confirm
E PF F
..
OK
E PF F
..
OK
E PF F
..
OK
