Imesa ES55 - Page 4

E980702H 02/12/04
4
RISCALDAMENTO A GAS / GAS HEATED / CHAUFFAGE A GAZ / GAS HEIZUNG / CALENTAMIENTO GAS
Tab.4
Modello
Model
Modèle
Typ
Modélo
ES10
GAM
(TD10)
ES10
GAB
(TD10)
ES14
GAM
(TD14)
ES14
GAB
(TD14)
ES18
GAB
(TD18)
ES23
GAC
(TD23)
ES34
GAD
(TD34)
ES55
(TD55)
Potenza di riscaldamento
Heating power
Puissance chauffage
Heizleistung
Potencia calentamiento
kW
14.5 29 14.5 29 29 37.8 50.4 87
Capacità (DIN 30682)
Capacity (DIN 30682)
Capacité (DIN 30682)
Füllmenge (DIN 30682)
Capacidad (DIN 30682)
Kg
5.6 7 8.6 11 14 18 26 32
Allacciamento gas
Gas connection
Branchement gaz
Gasanschluß
Conexión gas
R½” R½” R½” R½” R½” R¾” R¾” R1”
Tensione di alimentazione
Power supply voltage
Voltage d’alimentation
Spannung
Voltaje de red de alimentación
AC 400 3N V 50 Hz
Potenza installata
Power
Puissance
Anschlußleistung
Potencia
kW
0.35 0.35 0.4 0.4 0.4 0.9 1.0 2.0
Cavo d’allacciamento
Connection wire
Cable de branchement
Anschlußkabel
Cable de conexión
mm
2
5 x 1.5 5 x 2.5
Tab.5 (ITALIA)
Modello
ES10
GAM
(TD10)
ES10
GAB
(TD10)
ES14
GAM
(TD14)
ES14
GAB
(TD14)
ES18
GAB
(TD18)
ES23
GAC
(TD23)
ES34
GAD
(TD34)
ES55
(TD55)
Gas METANO
2H (G20)
Potere calorifero inf. 34.02 MJ/m
3
Pressione nominale 2000 Pa
Pressione massima 2500 Pa
Pressione minima 1700 Pa
Ugelli Φ mm 1 x 2.90 2 x 2.90 1 x 2.90 2 x 2.90 2 x 2.90 3 x 2.70 4 x 2.70 3 x 4.0
Consumo m
3
/h 1.53 3.07 1.53 3.07 3.07 4.0 5.33 8.0
Gas LIQUIDO
3+ (G30)
Potere calorifero inf. 45.65 MJ/Kg
Pressione nominale 2800 – 3000/3700 Pa
Pressione massima 3500/4500 Pa
Pressione minima 2000/2500 Pa
Ugelli Φ mm 1 x 1.85 2 x 1.85 1 x 1.85 2 x 1.85 2 x 1.85 3 x 1.75 4 x 1.75 3 x 2.7
Consumo Kg/h 1.14 2.29 1.14 2.29 2.29 2.98 3.97 6.0
Tipo B22
Φ interno uscita fumi (mm) 150 150 150 150 150 200 200 300
pressione massima in canna fumaria 150 Pa
