Audax TOP 6 e 8 ErP
Audax TOP 12 ErP Audax TOP 16 ErP
11
INSTALLERUSER
MAINTENANCE TECHNICIAN
Key:
A - Position of 4 Inverter Board Diagnostics LEDs (Audax TOP 12 ErP and Audax TOP 16 ErP only)
B - GMC Board
C - Installation terminal board
D - Cable tie
