Immergas AUDAX TOP 6 ErP Instruction And Recommendation Booklet

19
INSTALLERUSER
MAINTENANCE TECHNICIAN
• Time ranges. e remote panel enables you to
set 4 calendars with 4 time operating ranges in
system comfort mode. e system will operate
in economy mode during out-of-range time of
these time ranges.
Aer setting these 4 calendars it is possible to
associate them to the various days of the week
and DHW function according to one's needs.
- Press the “Menu” button, select item “Orolo-
gio e Programmi” (Clock and Programs)
from the main switch (ref. 1 g. 2-1), then
press “Fasce orarie” (Time ranges).
- Once you have accessed the menu, adjust the
various items highlighted by turning the main
switch. Set the value and save it by pressing
the main switch. Each time it is saved, it
moves to the next item.
- Aer programming, press “Conferma” (Con-
rm).
IMPOSTA DATA E ORA
Time program
Cancel Conferm
Calendar: 1
[1] 06:15 - 08:30 [3] 17:45 - 23:00
[2] 11:30 - 13:45 [4] 24:00 - 24:00
0 2 4 6 8 10 12 14 16 18 20 22 24
2-4
• Programma di Zona (Zone Programming).
Time ranges (Calendars from 1 to 4) are as-
signed to Zones in these menus. You can assign
the calendar to a single day or to a group of
days. (single day, Monday - Friday, Saturday -
Sunday, Monday - Saturday, Monday - Sunday).
erefore each day may be personalised with
4 dierent operating programs.
For convenient selection, the bottom part
displays the graphics of the relevant calendar
being selected (refer to the following g.).
IMPOSTA DATA E ORA
Program Zone
Esc Back
Days: Monday - Sunday
Calendar: 1
0 2 4 6 8 10 12 14 16 18 20 22 24
2-5
• Programma vacanze (Holiday programming)
( ). If required, it is possible to pause
system operation for an established period.
Access the “Orologio e programmi” (Clock and
Programs) menu, select “Programma vacanze”
(Holiday programming) and set the period in
which you wish to pause system operation.
During this time, the previously set calendars
will not be taken into consideration.
e antifreeze function is still ensured during
the holiday period.
IMPOSTA DATA E ORA
Program holiday
Cancel Conferm
DAY MONTH YEAR
Start: 02 08 2014
Stop: 23 08 2014
Enable holiday: Yes
2-6
2.6 COMFORT / ECONOMY / MANUAL
OPERATION.
Once the calendar is set and the relative asso-
ciation of days is executed, the system operates
automatically by switching from “comfort” to
“economy” according to what has been set.
• Comfort ( ). During periods in comfort
mode, a relative icon appears next to the op-
eration mode.
• Economy ( ). During periods in economy
mode, a relative icon appears next to the op-
eration mode.
• Manual ( ). If the remote panel was set to
manage the room temperature of the zone,
if required, it is possible to change the value
manually for a determined range.
Turning the main switch changes the room
temperature, and pressing it confirms the
change. e change is displayed by the symbol
“ ”. is change remains active until the next
time range is changed from the active calendar.
2.7 EXTERNAL PROBE OPERATION.
When the system is associated with the external
probe, the relative symbol ( ) is displayed.
From this moment, the system's ow temper-
ature for room central heating is managed by
the external probe depending on the external
temperature measured (Par. 3.2 “Assistance”
“Central heating thermoregulation” menu ). It is
possible to change the operation curve by using
the main switch and changing the external probe
oset (Fig. 3-2).
2.8 CLOCK AND PROGRAMS.
From this menu, it is possible to set the system's
date and time as well as the time ranges for op-
eration in comfort and economy mode.
• Date and time. On rst electric supply voltage
from the remote panel, or in the event of a
voltage drop, you must set the date and time.
Proceed as follows:
- Press the “Menu” button (ref. 3 g. 2-1), select
item “Orologio e Programmi” (Clock and
Programs) from the main switch (ref. 1 g.
2-1), then press “Data e ora” (Date and time).
- Once you have accessed the menu, adjust the
various items highlighted by turning the main
switch. Set the value and save it by pressing
the main switch. Each time it is saved, it
moves to the next item.
- Aer programming, press “Conferma” (Con-
rm).
SETTING DATE AND HOUR
Cancel Conferm
DAY MONTH YEAR
Date: 24 Apr 2014
HOUR MINUTE
Hour: 15 56
2-3
