Immergas AUDAX TOP 6 ErP Instruction And Recommendation Booklet




  
 
C
B
A
A
L N
B
Y/G
3-1
24
INSTALLERUSER
MAINTENANCE TECHNICIAN
3
CHECKS AND MAINTE
NANCE.
Assistance and maintenance
Attention:
• Make sure that personnel wear personal pro-
tective equipment.
• Extraordinary maintenance operations must
be carried out by qualied personnel.
N.B.: disconnect the mains supply voltage before
starting any maintenance operations or before
handling any components inside the unit.
Attention:
• e air conditioning unit contains coolant that
requires special disposal.
• Aer its useful lifespan, remove the air-condi-
tioning unit with care.
• e air-conditioning unit must be taken to
special collection centres or dealers who will
provide for its proper and suitable disposal.
- using an omnipolar disconnecter, check con-
nection to 230V-50Hz mains power supply,
correct L-N polarity and the earthing connec-
tion;
- make sure the central heating system is lled
3.1 AUDAX TOP 6 ErP WIRING DIAGRAM.
with water and that the manometer indicates
a pressure of 1÷1.2 bar.
- make sure that the air vent valve cap (if present)
is open and that the system is well deaerated;
- check activation of the main switch located
upstream of Audax Top ErP;
- check sealing eciency of water circuits;
- check correlation between the electric and
hydraulic connections;
If even only a single safety check oers a negative
result, do not commission the system.
Key: = Manufacturer's wiring = Installer's wiring CM = Compressor motor FM = Fan motor RV = Reversing valve (4-way) TS = Low-pressure pipe temperature
probe
TO = Outdoor unit temperature probe TD = High-pressure pipe temperature
probe
TE = Condenser pipe temperature probe PMV = Modulating valve motor R = Inductance F = Fuse FL = Filter Cable colour: R = Red Y = Yellow O = Orange A = Brown C = Black V = Purple B = Blue W = White Y/G = Yellow/Green
