Immergas AUDAX TOP 6 ErP Instruction And Recommendation Booklet

3-3
33
INSTALLERUSER
MAINTENANCE TECHNICIAN
LED status (Initial display) LED status pressing SW800 Type of error
lllll lllll
Normal (no error)
ll
ll¤ll
Flow temperature sensor error (TD)
l¤¤ll
Battery temperature sensor error (TE)
¤¤¤ll
Battery temperature sensor error (TL)
lll¤l
Outdoor temperature sensor error (TO)
ll¤¤l
Intake temperature sensor error (TS)
¤l¤¤l
Heat dissipator temperature sensor error (TH)
¤¤¤¤l
Sensor wiring error (TE and TS)
¤¤¤¤¤
EEPROM error
lll
¤llll
Compressor fault
l¤lll
Compressor block
¤¤lll
Current sensor error
ll¤ll
ermostat operation
ll
l¤l¤l
Size not set
¤l¤¤¤
Communication error between the boards
¤¤¤¤¤
Other errors
l
¤¤lll
Flow temperature error
¤l¤ll
Supply voltage error
¤¤¤ll
Heat dissipator overheating error
¤¤¤¤l
Detection of gas leakages
¤¤ll¤
Reversing valve error
ll¤l¤
High pressure protection
l¤¤l¤
Ventilation system error
l¤l¤¤
Pilot elements short circuit
¤l¤¤¤
Detection circuit error
Key
l
O

On
¤
Flashing
D800 (Yellow)
D801 (Yellow)
D802 (Yellow)
D803 (Yellow)
D804 (Yellow)
D805 (Yellow)
3.8 INVERTER BOARD ALARM CODES
AUDAX TOP 16 ErP ONLY.
e error currently veried and the last error
(the last error includes the current error) are
conrmed by LEDs D800 to D804 lighting up
on the inverter board.
a) e current error is displayed when all the
SW803 switches are in an OFF position.
b) If only switch 1 of SW803 is lit, the last error
is displayed (the last error includes the current
error)
c) If there is an error, LEDs D800, D801, D802,
D803, and D804 light up.
d) If SW800 is pressed for approximately 1
second, the LED's display status will change,
refer to the table.
e) When SW800 is pressed again, or after 2
minutes, the display goes back to the relative
display 1.
ON
ON
2 3 41 2 3 41
Current
error
SW803
Last error
SW803
