STEEkW ed 01/06 EOLO Extra kW
Technical Documentation
Technical Documentation
Legend:
1 - Stand by LED
2 - Burner on LED
3 - D.h.w. on LED
4 - Central heating on LED
5 - Temperature LED – Ignition stop malfunction
6 - Temperature LED – Flue pressure switch malfunction
7 - Temperature LED – System pressure insufficient malfunction
8 - Temperature LED – Circulation insufficient malfunction
9 - Temperature LED – Delivery probe faulty
10 - Temperature LED – Domestic hot water probe faulty (optional)
11 - Temperature LED – Overheating lock
12 - Stand-by / On / Programming / Reset main switch
13 - Parameters selection knob
14 - Parameters modification knob
15 - Boiler manometer
EOLO Extra kW Control panel.
