EOLO STAR
COMBUSTION PARAMETERS
(with combustion air temperature 15 ºC )
G20
G30 G31
Rated power fume mass flow kg/h 58 56 56
Minimum power fume mass flow kg/h 61 61 61
CO
2
at rated power % 6.3 7.6 7.5
CO
2
at minimum power % 2.5 2.9 2.9
CO at 0% of O
2
at rated power ppm 58 115 66
CO at 0% of O
2
at minimum power ppm 70 85 79
No
x
at 0% of O
2
at rated power ppm 68 226 200
No
x
at 0% of O
2
at minimum power ppm 50 134 103
Fume temperature at rated power ºC 122 122 123
Fume temperature at minimum power ºC 100 101 100
THERMAL POWER ADJUSTMENTS
NATURAL GAS (G20) BUTANE (G30) PROPANE (G31)
Thermal
power
(kcal/h)
Thermal
power
(kW)
Burner gas
flow
(m
3
/h)
Burner nozzle
pressure
(mbar) (mm H
2
O)
Burner gas
flow
(kg/h)
Burner nozzle
pressure
(mbar) (mm H
2
O)
Burner gas
flow
(kg/h)
Burner nozzle
flow
(mbar) (mm H
2
O)
20000 23.3 2.72 10.7 109 2.03 27.7 283 2.00 35.7 364
19000 22.1
C.
2.60 9.8 100 1.94 25.3 258 1.91 32.6 333
18000 20.9 2.47 8.8 90 1.84 22.8 232 1.81 29.4 300
17000 19.8
H
2.34 7.9 81 1.74 20.4 208 1.72 26.3 269
16000 18.6
E
2.21 7.0 72 1.65 18.2 186 1.62 23.5 240
15000 17.4
A
2.08 6.3 64 1.55 16.2 165 1.53 20.9 213
14000 16.3
T
1.96 5.5 56 1.46 14.3 146 1.44 18.4 188
13000 15.1
I
1.83 4.8 49 1.36 12.5 128 1.34 16.1 164
12000 14.0
N
1.70 4.2 43 1.27 10.8 111 1.25 14.0 143
11000 12.8
G
1.58 3.6 37 1.17 9.3 95 1.16 12.0 122
10000 11.6 1.45 3.0 31 1.08 7.9 80 1.06 10.1 103
9000 10.5 1.32 2.5 26 0.98 6.5 67 0.97 8.4 86
8000 9.3 1.19 2.3 23 0.89 5.6 57 0.87 7.2 73
6000 7.0
Hot
water
0.88 1.1 11 0.65 3.0 31 1.06 3.6 37
