INTRODUCING THE
PRODUCT
2.1 IMPORTANT ADVICE.
Inspecting and handling the unit.
Upon delivery, check the packaging and immedi-
ately report any damage to the shipping company.
Consider the following when handling the unit:
•
Fragile, handle with care.
• Choose the route for transporting the unit in
advance.
• Move the unit in its original packaging, if
possible.
• Use special protective devices when liing the
unit so as not to damage the belts, and pay
attention to the position of the unit’s centre
of gravity.
2.2 TECHNICAL SPECIFICATIONS.
We recommend you strictly follow these in-
structions.
e product warranty is rendered null and void
if the above instructions are not complied with.
e manufacturer declines any liability for any
faults to the product resulting from transport or
handling not complying with the above recom-
mendations.
Maximum operating temperature 1.6 Mpa
Minimum operating temperature 0.15 Mpa
Relative humidity < 90% (normal 0 ~ 80%)
Minimum cooling water inlet temperature 3°C
Maximum cooling water inlet temperature 70°C (normal 50°C)
Water pH 6.5 ~ 7.5
Cooling / Heating
Inside temperature 17°C ~ 32°C / 0°C ~ 30°C
Water inlet temperature 3°C ~ 20°C / 30°C ~ 70°C
2.3 ACCESSORIES PROVIDED.
Make sure the package contains all of the instal-
lation accessories.
Name Figure Quantity Function
ST3.9x25 screw for installation
panel
8 Fixing the installation panel
Plastic foam pipe
8
Wrapping tape
1
Drain pipe
1
Wall-mounted pipe cover
1
Remote control (with operating
manual)
1
Remote control mount
1 Mount for the remote control
Assembly screw (ST2.9
10-C-H)
2
Installing the remote control
mount
Alkaline batteries (AM4)
2 For the remote control
Cable for ON/OFF switch
1
Installation manual
1 is manual
Gasket
4 For connecting the water pipe
