INSTALLERUSERMAINTENANCE TECHNICIAN
1.13 OUTDOOR INSTALLATION IN
PARTIALLY PROTECTED AREA.
N.B.: a partially protected location is one in which
the appliance is not exposed to the direct action of
the weather (rain, snow, hail, etc..)..
is type of installation is only possible when
permitted by the laws in force in the appliance's
country of destination.
Conguration type B, open chamber and fan
assisted.
Using the special coverage kit one can achieve
direct air intake (Fig. 10) and ue gas exhaust
in a single chimney or directly outside. In this
conguration it is possible to install the indoor
unit in a partially protected place. In this cong-
uration the indoor unit is classied as type B
23
.
With this conguration:
- air intake takes place directly from the envi-
ronment in which the appliance is installed
(external);
- the ue gas exhaust must be connected to its
own single ue (B
23
) or ducted directly outside
via a vertical terminal for direct exhaust (B
53
)
or via an Immergas ducting system (B
53
).
The technical regulations in force must be
respected.
Coverage kit assembly (Fig. 11). Remove the
two plugs from the two lateral holes. Install the
Ø 80 outlet ange on the central hole of the
heat generator, taking care to insert the gasket
supplied with the kit and tighten by means of
the screws provided. Install the upper cover,
xing it using the 4 screws present in the kit,
positioning the relevant gaskets. Engage the
90° Ø 80 bend with the male end (smooth) in
the female end (with lip seal) of the Ø 80 ange
unit until it reaches the end stop. Introduce
the gasket, making it run along the bend. Fix
it using the metal-sheet steel plate and tighten
by means of the clip present in the kit, making
sure to block the 4 gasket aps. Fit the male
end (smooth) of the exhaust terminal into the
female end of the bend 90° Ø 80, making sure
that the relevant wall sealing plate is already
tted; this will ensure hold and joining of the
elements making up the kit.
Max. length of exhaust duct. e ue pipe (both
vertical or horizontal) can be extended to a max.
length of 30 linear metres.
Coupling of extension pipes. To install
push-tting extensions with other elements
of the ue, proceed as follows: Install the pipe
or elbow with the male side (smooth) in the
female section (with lip seal) to the stop on the
previously installed element. is will ensure
sealing eciency of the coupling.
Conguration without cover kit in a partially
protected location (type C heat generator)
By leaving the side plugs tted it is possible
to install the appliance externally without the
cover kit. Installation takes place using the
Ø60/100, Ø 80/125 and separator Ø 80/80
concentric intake/ exhaust kits. Refer to the
paragraph relative to indoor installation. In
this conguration the upper cover kit assures
additional protection for the indoor unit. It is
recommended but not compulsory.
e cover kit includes:
N° 1 Heat moulded cover
N°1 Gasket clamping plate
N°1 Gasket
N°1 Gasket clamp
N°1 N°1 Intake hole covering plate
e terminal kit includes:
N° 1 Gasket
N° 1 Exhaust ange Ø 80
N° 1 Bend 90° 80 Ø
N° 1 Exhaust pipe Ø 80
N° 1 Wall sealing plate
