Immergas VICTRIX PRO 35 V2 - Page 7

Scambiatori a piastre in
abbinamento a
VICTRIX PRO V2 /
Plates exchangers
paired with
VICTRIX PRO V2
(kW)
N° piastre/
N° plates
Massima potenza
gestita/
Maximum power
(kW)
Portata Primario /
Primary ow rate
(m
3
/h) M/R 80°/65°
Portata Secondario /
Secondary ow rate
(m
3
/h) M/R 70°/60°
p (m.c.a.) Peso solo
scambiatore
/ Weight
of the heat
exchanger
only
(kg)
Circuito prima-
rio T 15°C/
Primary circuit
T 15°C
Circuito seconda-
rio T 10°C
Secondary
circuit T 10°C
175 90 400 10.0 15.0 0.41 0.94 31.3
200 90 400 11.5 17.2 0.53 1.23 31.3
250 90 400 14.3 21.5 0.83 1.91 31.3
275 90 400 15.7 23.6 1.0 2.32 31.3
300 90 400 17.2 25.8 1.2 2.76 31.3
350 90 400 20.0 30.0 1.63 3.75 31.3
400 90 400 22.9 34.4 2.25 4.9 31.3
Kit cod. 3.033679
Volumi contenuto d'acqua nel kit in abbinamento alla:
Volumes of water content in the kit in combination with:
Modello/
Model
Contenuto litri impianto/
System litres content
Capacità vaso espansione (litri)/
Expansion vessel capacity (litres)
N° 2 Victrix Pro 100 V2 75 8
N° 3 Victrix Pro 100 V2 100 8
N° 4 Victrix Pro 100 V2 125 12
N° 5 Victrix Pro 100 V2 150 12
N° 2 Victrix Pro 120 V2 77 8
N° 3 Victrix Pro 120 V2 103 8
N° 4 Victrix Pro 120 V2 129 12
N° 5 Victrix Pro 120 V2 155 12
N° 2 Victrix Pro 150 V2 81 8
N° 3 Victrix Pro 150 V2 109 12
N° 4 Victrix Pro 150 V2 137 12
N° 5 Victrix Pro 150 V2 165 18
Dati Tecnici/Technical data
Scambiatori a piastre in
abbinamento a
VICTRIX PRO V2 /
Plates exchangers
paired with
VICTRIX PRO V2
(kW)
N° piastre/
N° plates
Massima potenza
gestita/
Maximum power
(kW)
Portata Primario /
Primary ow rate
(m
3
/h) M/R 80°/65°
Portata Secondario /
Secondary ow rate
(m
3
/h) M/R 70°/60°
p (m.c.a.) Peso solo
scambiatore
/ Weight
of the heat
exchanger
only
(kg)
Circuito prima-
rio T 15°C/
Primary circuit
T 15°C
Circuito seconda-
rio T 10°C
Secondary
circuit T 10°C
400 100 850 22.9 34.4 0.53 1.15 65
450 100 850 25.8 38.7 0.67 1.45 65
500 100 850 28.7 43.0 0.83 1.79 65
550 100 850 31.5 47.3 1.0 2.17 65
600 100 850 34.4 51.6 1.2 2.58 65
650 100 850 37.2 55.9 1.4 3.03 65
700 100 850 40.1 60.2 1.63 3.51 65
750 100 850 43.0 64.5 1.87 4.03 65
STD.010398/000
