Scambiatori a piastre in
abbinamento a
VICTRIX PRO V2 /
Plates exchangers
paired with
VICTRIX PRO V2
(kW)
N° piastre/
N° plates
Massima potenza
gestita/
Maximum power
(kW)
Portata Primario /
Primary ow rate
(m
3
/h) M/R 80°/60°
Portata Secondario /
Secondary ow rate
(m
3
/h) M/R 70°/55°
p (m.c.a.) Peso solo
scambiatore
/ Weight
of the heat
exchanger
only
(kg)
Circuito prima-
rio T 20°C/
Primary circuit
T 20°C
Circuito seconda-
rio T 15°C
Secondary
circuit T 15°C
400 100 850 17.2 22.9 0.27 0.5 65
450 100 850 19.3 25.8 0.35 0.64 65
500 100 850 21.4 28.7 0.43 0.79 65
550 100 850 23.6 31.5 0.5 0.96 65
600 100 850 25.8 34.4 0.62 1.14 65
650 100 850 27.9 37.2 0.73 1.34 65
700 100 850 30 40.1 0.84 1.56 65
750 100 850 32.2 43 0.97 1.79 65
