Chapter8 Communication Function
8-10
Remark
1) Numerical data of frame(Ex.) is hex value, and "H" is unnecessary during preparing real frame.
2) Device data type of each must be same. If data type of the first block is WORD, and the second block is
BIT, error occurs.
(3) Response format (ACK response)
Format name Header
Station
No.
Command
Command
type
Number of
blocks
Number
of data
data Tail
Frame
check
Ex. of frame ACK H20 R(r) SS H01 H02 HA9F3
......
ETX BCC
ASCII value H06 H3230 H52(72) H5353 H3031 H3032 H41394633 H04
1 block( max. 16 blocks possible)
Item Explanation
BCC
When command is lowercase(r), only one lower byte of the value resulted by adding 1 Byte
each to ASCII values from ACK to ETX is converted into ASCII and added to BCC, and
sent.
Number of data
Number of data means byte number of hex type, and is converted into ASCII. This number
is determined according to data type(X,W) included in device name of computer request
Format.
Number of data in accordance with its data type is as follows:
Data • In data area, there are the values of hex data converted to ASCII code saved.
Ex.1
The fact that number of data is H04(ASCII code value:H3034) means that there is hex data of 4 bytes in data .
Hex data of 4 bytes is converted into ASCII code in data.
Data type Available variable Number of data
Bitl(X) %(P,M,L,K,T,C,F)X 1
Word(W) %(P,M,L,K,T,C,D,S,F)W 2
