Chapter 4. Names of Parts
4
-
ొ
4.2 Expansion Module
4.2.1 Digital I/O Module
4.2.2 A/D
h
D/A Combination Module
No.
Names
①
RUN LED
②
Analog Input Terminal
③
Analog Input (Voltage/current) selecting jumper pin
④
Analog Output Terminal
⑤
External Power Supply Terminal (DC24V)
⑥
Expansion Cable
⑦
Expansion Cable Connecting Terminal
4.2.3 Analog Timer Module
No.
Names
①
RUN LED
②
Analog Timer Volume Control Resistance
③
Expansion Cable
④
Expansion Cable Connecting Terminal
①
②
③
④
⑦
①
②
③
④
⑤
⑥
