Chapter 2 System Configuration

2-3

(3) RS-232C Communication over a long distance via modem by Cnet I/F modules

2) 1:n Communications system

This method can connect between one computer and mutilpe main units for up to 32 stations

Modem

G7L-CUEB

RS-232C

ሒ

RS-422 Converter

Can be connected Max. 32 stations

G7L-CUEC
