IMO Precision Controls K7M-DR30S User Manual

Chapter 7 Usage of Various Functions
7-
ేె
(5) 2-phase operation mode (4 Multiplication Operation : D4999 = h2014)
U/D : set automatically by the phase difference between A and B phase
PR : set by external PR input
Multiplication : 4 times
Ladder diagram
Time chart
HSC
EN
U/D PV 00100
PR SV 01000
MOV h2014 D4999
M000
A
-
p
hase
p
ulse in
p
ut
B-
p
hase in
p
ut
(
U/D
)
Current value of HSC 10 14 16 18 20 22 24 25
23
21 19 17 1512
15 19 23
24
20 1611 17 21 25 22 18 1413
F012
M001
M002
