9-21 Specifications
9
(2)Functions for standard frame (monitor data)
Name Command Function type Data and operation
type character and
character number
Frequency R M01 ±20000d/fmax (Max. frequency)
(Final value)
Frequency R M05 100=1.00Hz (Value multiplied by 100)
command value The current frequency setting is returned.
Calculated torque R M07 100% (rated torque) / ± 10000 (value multiplied
value by 100)
Torque current R M08 100% (rated current) / ± 10000
(value multiplied by 100)
Output frequency R M09 100=1.00Hz
(Value multiplied by 100; special additional data: sign)
The current output frequency is returned.
Motor output R M10 100% (rated output) / ± 10000
(power (value multiplied by 100)
consumption)
Output current R M11 100 = 1% of rated inverter current
The current output current is returned in the ratio to
the rated current.
Output voltage R M12 10=1V
Operation R M13 bit15:RESET 1:ON,0:OFF
command bits 14 to 5: Fixed to 0
bit6:X5 1:ON, 0:OFF
bit5:X4 1:ON, 0:OFF
bit4:X3 1:ON, 0:OFF
bit3:X2 1:ON, 0:OFF
bit2:X1 1:ON, 0:OFF
bit 1: REV (reverse rotation command)
1:ON,0:OFF
bit 0: FWD (forward rotation command)
1:ON,0:OFF
The final command value including the state of the
actual control terminal of the inverter is returned.
Operation status R M14 bit 15: Function code data being written
bit 12: 1: Communication valid
bit 11: 1: Batch failure (tripping)
bit 10: 1: During deceleration
bit 9: 1: During acceleration
bit 8: 1: Current limit operation
bit 7: 1: Voltage limit operation
bit 6: 1: Torque limit operation
bit 5: 1: DC link voltage established
bit 4: 1: During braking
bit 3: 1: During output shutoff
bit 2: 1: During DC braking
bit 1: 1: During reverse rotation
bit 0: 1: During forward rotation
General purpose R M15 bit 1: Y2; active upon "1"
output terminal bit 0: Y1; active upon "1"
Table 9-4-6 Standard frame (monitor data)
