9-1 Specifications
9
*1 The applicable standard motor indicates a 4
pole machine.
*2 The rated capacity indicates 230V output
voltage.
*3 Voltages larger than the source voltage
cannot be output.
*4 Amperage values in brackets () are
applicable to operation with 4 kHz or higher
carrier frequencies (F26 = 4 or more) or
ambient temperatures exceeding 40 degree C.
*5 Tests at standard load condition (85% load)
*6 Indicates the value when using a DC reactor
(DCR).
Item Detail specifications
Inverter type
VXSM 40-1 75-1 150-1 220-1
Nominal applied motor *
1
[kW]
0.4 0.75 1.5 2.2
Rated capacity *
2
[kVA] 1.1 1.9 3.1 4.3
Rated voltage *
3
[V] Three-phase 200V / 50 Hz, 200V, 220V, 230V / 60 Hz (with AVR function)
Rated current *
4
[A] 3.0 5.0 8.0 11
(2.5) (4.0) (7.0) (10)
Overload capability 150% of rated output current for 1 min.
200% of rated output current for 0.5 s
Rated frequency [Hz] 50, 60Hz
Phases, Voltage, Single-phase 200 to 240 V / 50 to 60 Hz *
10
Frequency
Voltage/frequency Voltage : +10 to -10%
fluctuation Frequency : +5 to -5%
Momentary voltage Operation continues at 165V or higher voltage. When the input voltage
dip capability *
5
drops below 165V from the rated voltage, operation continues for 15 ms.
Rated current [A] 3.5 6.5 11.8 17.7
(With DCR)
(Without DCR) *
9
6.4 11.4 19.8 28.5
Required power supply 0.7 1.3 2.4 3.6
capacity *
6
[kVA]
Braking torque *
7
[%] 70 40
Braking torque *
8
[%] 150
DC braking Starting frequency: 0.0 to 60 Hz, braking current (0 to 100% in 1%
increment), braking time (0.0 to 30.0 s)
Enclosure (IEC60529) IP20
Cooling method Natural cooling Fan cooling
Mass [kg] 0.7 1.2 1.8 1.9
9. Specifications
9-1 Standard Specifications
(1) Single-phase 200V input
Output ratingsInput ratings
Braking
*7 Indicates the average braking torque for
decelerating and stopping a discrete motor
from 60 Hz. (Varies according to the
efficiency of the motor.)
*8 Indicates the value with an external braking
resistor (option).
*9 Calculated on assumption that the inverter
is connected to 500kVA power supply.
*10 Safe separation for control interface of this
inverter is provided when this inverter is
installed in overvoltage category II. Basic
insulation for control interface of this
inverter is provided when this inverter is
installed in overvoltage category III.
