Specifications 9-26
9
1514131211109876543210
00000000000000X2X1
(9) Data format 9
General-purpose output terminal
Unused General-purpose input
(All bits: "1" when turned on)
Example: In the case that M15: (general-purpose output terminal) = 0000 0000 0000 0001 (bin.):
Y1 = ON
M15 = 0001 (hex.), hence: 0001
➾
0001
1514131211109876543210
–
RESET
RL
ALM
DEC
ACC
IL
VL
TL
NUV
BRK
INT
EXT
REV
FWD
(10) Data format 10
Operation state
(All bits: "1" when turned on or active)
FWD: During forward rotation
REV: During reverse rotation
EXT: During DC braking
INT: Inverter shutdown
BRK: During braking
NUV: DC link established
TL: Torque limit operation
VL: Voltage limit operation
IL: Current limit operation
ACC: During acceleration
DEC: During deceleration
ALM: Batch alarm
RL: Transmission valid/invalid
BUSY: During data writing (processing)
Example) ... Omitted (The monitoring method is similar to format 8.)
