5-4 Selecting Functions
5
Min. Factory
Name Setting range unit setting
E01 X1 terminal function 0: Multistep frequency selection [SS1] 0 X 0
1: Multistep frequency selection [SS2]
2: Multistep frequency selection [SS4]
3: Multistep frequency selection [SS8]
E02 X2 terminal function
4:Acceleration/deceleration time
1X0
selection [RT1]
5: 3-wire operation stop command [HLD]
6: Coast-to-stop command [BX]
7: Alarm reset [RST]
E03 X3 terminal function
8: Trip command(External fault) [THR]
2X0
9: Frequency setting 2/1 [Hz2/Hz1] 1
10: Motor 2/ Motor 1 [M2/M1]
11: DC brake command [DCBRK]
12: Torque limiter 2/Torque limiter 1
E04 X4 terminal function
[TL2/TL1]
6X0
13: UP command [UP]
14: DOWN command [DOWN]
15: Write enable for KEYPAD [WE-KP]
E05 X5 terminal function
16: PID control cancel [Hz/PID]
7X0
17: Inverse mode changeover [IVS]
(terminal 12 and C1)
18: Link enable [LE]
E10 Acceleration time 2 0.01 to 3600s 0.01s 10.0 6
E11 Deceleration time 2 10.0 6
E16 Torque limiter 2 20 to 200% 1% 180 0
(Driving) 999: Inactive
E17 (Brake) 0%: Automatic deceleration control,
20 to 200% 1% 150 0
999: Inactive
E20 Y1 terminal function 0: Inverter running [RUN] 0 X 0
1: Frequency equivalence [FAR]
2: Frequency level detection [FDT]
3: Undervoltage detection signal [LV]
4: Torque polarity [B/D] 1
E21 Y2 terminal function 5: Torque limiting [TL] 7 X 0
6: Auto restarting [IPF]
7: Overload early warning [OL]7
8:Life time alarm [LIFE]
9:Frequency level detection 2 [FAR2]
E29 Frequency level 0.01 to 10.0s 0.01s 0.1 6
detection delay
E30 FAR function signa l0.0 to 10.0Hz 0.1Hz 2.5 2
(Hysteresis)
E31 FDT function signal 0 to 400Hz 1Hz 50 0
(Level)
E32 (Hysteresis) 0.0 to 30.0Hz 0.1Hz 1.0 2
E33 OL function signal 0: Electronic thermal overload relay
(Mode select) 1: Output current 1 0 0
E34 (Level) 20 to 200% of the rated inverter current 0.01A
rated
motor
curren
t 6
E35 (Timer ) 0.0 to 60.0s 0.1s 10.0 2
E40 Display coefficient
A 0.00 to 200.0 0.01 0.01 6
E41 B 0.00 to 200.0 0.01 0.00 6
E42 LED display filter 0.0 to 5.0s 0.1s 0.5 2
Function code
Change during
operation
RS485 Data format
User setting
E: Extension terminal functions
