IMO VXSM550-3 - Alternative Motor Parameters: Motor 2 Details

Selecting Functions 5-39
5
of motor 2 poles
The number of poles of driven motor 2. This
parameter functions in the same way as P01
"Number of motor 1 poles". For the description,
refer to P01 "Number of motor 1 poles)".
Motor 2 (Capacity)
The capacity of motor 2. This parameter
functions in the same way as P02 "Motor 1
(Capacity)". For the description, refer to P02
"Motor 1 (Capacity)". However, the function of
related motor data changes to A12 "Motor 2
(Rated current)", A15 "Motor 2 (No-load
current)", A16 "Motor 2 (%R1 setting)" and A17
"Motor 2 (%X setting)".
Motor 2 (Rated current)
The rated current of motor 2. This parameter
functions in the same way as P03 "Motor 1
(Rated current)". For the description, refer to
P03 "Motor 1(Rated current)".
Motor 2 (Tuning)
Tuning of motor 2. This parameter functions in
the same way as P04 "Motor 1 (Tuning)". For
the description, refer to P04 "Motor 1 (Tuning)".
Motor 2 (Online turning)
Online tuning of motor 2. This parameter
functions in the same way as P05 "Motor 1
(Online tuning)". For the description, refer to
P05 "Motor 1 (Online turning)".
Motor 2 (No-load current)
The no-load current of motor 2. This parameter
functions in the same way as P06 "Motor 1 (No-
load current)". For the description, refer to P06
"Motor 1 (No-load current)".
Motor 2 (%R1 setting)
Motor 2 (%X setting)
%R1 and %X of motor 2. These parameters
function in the same way as P07 "Motor 1 (%R1
setting)" and P08 "Motor 1 (%X setting)". For the
description, refer to P07 and P08.
Motor 2 (Slip compensation
control 2)
The slip compensation control of motor 2. This
parameter functions in the same way as P09
"Motor 1 (Slip compensation control 1)". For the
description, refer to P09 "Motor 1 (Slip
compensation control 1)".
A18
A17
A16
A15
A14
A13
A12
A11
A10
Motor 2 (Slip compensation
response time 2)
Set the response time for slip compensation of
motor 2. This parameter functions in the same
way as P10 "Motor 1 (Slip compensation
response time)". For the description, refer to
P10 "Motor 1 (Slip compensation response
time)".
o: Optional function
Option selection
0: Option inactive
1: Option active
Set 0 when option card is used.
Refer to the instruction manual of option card
for detail of optional functions.
o00
A19
