30. Place Gasket (15) in place and align with screw
holes.
31. Insert two Screws (17) opposite each other in the
“Fuel In” cover and place on Gasket (15). Thread the
two Screws (17) through the gasket and into the Body
(9).
32. Insert remaining 8 Screws (17) in their openings.
