Impex AX-697 - Comprehensive Parts List

PARTS LIST
KEY NO. DESCRIPTION Q’ty
1 Left Upright Beam 1
2 Right Upright Beam 1
3 Cross Brace 1
4 Main Seat Support 1
5 Sliding Block 1
6 Seat Bracket 1
7 Crutch 2
8 Leg Developer Holder 1
9 Leg Developer 1
10 Arm Curl Stand 1
11 Backrest Incline Support 1
12 Backrest Support 2
13 Curl Bar Handle Support 1
14 Curl Bar Handle 1
15 Grip 2
16 Arm Curl Pad 1
17 Backrest Board 1
18 Seat 1
19 Seat Incline Adjustment 1
20 Crutch Sliding Sleeve 2
21 Crutch End Cap 2
22 4 ¾” x 2” Bracket 2
23 Lock Knob 4
24 4 3/8” x 1 ¾” Bracket 1
25 ∅ 2 3/8” Bushing 2
26 ∅ 1 ½” Bushing 2
27 Axle 1
28 Philips Screw 4
29 4” L-shaped Lock Pin 1
30 3” L-shaped Lock Pin 1
31 Foam Tube 3
32 Foam Roll 6
33 Foam Roll End Cap 6
34 Spring Clip 1
35 M8 x ¾” Allen Bolt 6
36 ∅ 5/8” Washer 10
37 M8 x 1 5/8” Allen Bolt 4
38 M10 x 2 ½” Carriage Bolt 4
39 ∅ ¾” Washer 16
40 M10 Aircraft Nut 11
41 M10 x 5/8” Allen Bolt 2
42 M10 x 7 ¼” Hex Bolt 2
43 M10 x 2 ¾” Carriage Bolt 4
44 M10 x 3 3/8” Allen Bolt 1
45 2” Square End Cap 4
46 ∅ 1” Cone-shaped End Cap 2
47 ∅ 1” End Cap 1
48 1 5/8” x 2 3/8” End Cap 2
49 1” Square End Cap 2
50 2 3/8” Block Sleeve 2
51 2” Sleeve 2
52 ∅ ¾” x ½” Bushing 6
53 ∅ ¾” x 3/8” Bushing 2
#5 Allen Wrench (Tool) 1
#6 Allen Wrench (Tool) 1
