SMITH MACHINE ASSEMBLY INSTRUCTION
Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen
Wrenches
NOTE: It is strongly recommended two or more people assembling this machine to
avoid possible injury.
STEP 1 (See Diagram 1)
A.) Do not tighten all nuts and bolts until instructed to do so.
B.) Attach one Guide Rod (#12) onto a Base Frame (#1). Secure the Guide Rod to the Base
Frame with one M10 x 1” Allen Bolt (#74) and Ø ¾” Washer (#86) from the bottom.
C.) Slide one Lower Safety Stop Frame (#90) onto the Guide Rod from the top then slide one
Safety Stop Frame (#26) onto the Guide Rod.
D.) Attach the Base Frame (#1) to the Left Vertical Frame (#3). Attach the Cross Brace (#8)
to the back of the Left Vertical Frame (#8). Align the holes and secure the Base Frame,
Left Vertical Frame, and the Cross Brace together with two M10 x 2 ¾” Carriage Bolts
(#70), two Ø ¾” Washers (#86), and two M10 Aircraft Nuts (#83).
E.) Insert the top of the Guide Rod (#12) into the tube on the Left Vertical Frame (#3). Secure
it with one M8 x 1 5/8” Allen Bolt (#76) and M8 Aircraft Nut (#75).
F.) Attach one Front Vertical Frame (#2) onto the Base Frame (#1). Secure it with two M10 x
2 ¾” Carriage Bolts (#70), one 4” x 2” Bracket (#36), two Ø ¾” Washers (#86), and two
M10 Aircraft Nuts (#83).
G.) Attach the top of the Front Vertical Frame (#2) to the top of the Left Vertical Frame (#3).
Secure it with two M10 x 1” Allen Bolts (#74) and Ø ¾” Washers (#86).
H.) Attach a Safety Hook (#91) to the Lower Safety Stop Frame (#90). Securely it with one
M10 x 1” Allen Bolt (#74), two Ø ¾” Washers (#86), and one M10 Aircraft Nut (#83).
Attach the Safety Hook into the selected hole on the back of Front Vertical Frame.
I.) Repeat Procedure B through H to install the other side.
