MULTI-PURPOSE BENCH ASSEMBLY INSTRUCTION
Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen
Wrenches. NOTE: It is strongly recommended this machine be assembled by two or
more people to avoid possible injury.
STEP 1 (See Diagram 1)
A.) Attach the Front Post (#3) to the Front Stabilizer (#17).
B.) Secure it with three M10 x 5/8” Allen Bolts (#40) and Ø 5/8” Washers (#39).
DIAGRAM 1
24
