Mounting the Impro (WRM) Wiegand Reader Module
CAUTION: Make certain that you mount the WRM on a vibration-free surface.
NOTE: The WRM can be mounted onto virtually any surface including metal.
NOTE: Cluster Modules are Hot-Swappable – it is not necessary to power them
down when adding, removing or wiring them up.
Clustering
Provided there are less than eight other Expansion Modules already clustered with the
Cluster Controller, you may add the WRM to an existing Cluster:
• Remove the Housing Cover from the WRM and plug the WRM into the Cluster
Socket on the right hand side of the Cluster Controller – or that of the
outermost Expansion Module in the cluster.
• Holding the WRM square against its neighbouring Module, mark the mounting
hole locations through the mounting holes in the back of the Housing Base.
• Remove the WRM, drill the mounting holes.
• Use the plastic Stand-Offs to provide space for cables behind the cluster, or if
the other modules in the Cluster are already mounted with stand-offs.
• Mount the WRM Housing Base firmly to the mounting surface using fasteners
(not included) appropriate for the mounting surface material.
• Select the gland plates that best suit the installation and/or knock out the
cable entry points as needed.
• Connect the reader cables, the digital inputs and the relay terminals as
necessary for the installation
• Commission the WRM (and its readers) via the menu options on the Access
Control Application.
• Replace the WRM Housing Cover and fasten closed with the two Allen head
screws provided.
Blank Space
HMW300-0-0-GB-00 October 2013 Page 7
