─ 56 ─
Tube Frame ASSY
Lat Pulldown / Vertical Row Exploded View and Parts List
Small Top Frame ASSY
ITEM NO.
Description QTY
1 Tube Frame 1
2 Bronze Bushing Φ38 1
ITEM NO.
Description QTY
1 Small Top Frame 1
2 Plug □50.8 2
3 Nut M8 2
